Flush Trim Bits
1/2 In. x 1-3/16 In. Carbide Tipped 1-Flute Pilot Panel Concave Bit
1/2 In. x 1-3/16 In. Carbide Tipped 1-Flute Pilot Panel Concave Bit
Carbide Tipped Trim Bit_OffsetBaseScribingFInal
Carbide Tipped Trim Bit_PR004HingeMortising
Carbide Tipped Trim Bit_PR20EVSK_Deck
Carbide Tipped Trim Bit_TiltBaseCornerTrimHand
Carbide Tipped Trim Bit_Trimming_B
1/2 In. x 1-3/16 In. Carbide Tipped 1-Flute Pilot Panel Concave Bit
1/2 In. x 1-3/16 In. Carbide Tipped 1-Flute Pilot Panel Concave Bit
Carbide Tipped Trim Bit_OffsetBaseScribingFInal
Carbide Tipped Trim Bit_PR004HingeMortising
Carbide Tipped Trim Bit_PR20EVSK_Deck
Carbide Tipped Trim Bit_TiltBaseCornerTrimHand
Carbide Tipped Trim Bit_Trimming_B

Single Flute Pilot Panel Bits with Drill-Through Point

For hand-held routers, For Palm Routers

  • Single Flute Pilot Panel Bits with Drill-Through Point provides a faster cut in abrasive materials
  • Single flute allows for faster feed rates
  • For window and door cutouts in abrasive insulation materials, plywood, and paneling
  • Drill-through pilot for guiding on templet or framing after panel has been mounted
  • Concave grind offers a faster cut
View more View less

Materials

Hardwood
Particleboard
Medium density fibreboard
Plywood
Softwood

Select options

Shank Inch

Diameter (D) Inch

Working length (L) Inch

Choose a pack size

Select options

Shank Inch 3 options

Diameter (D) Inch 3 options

Working length (L) Inch 6 options

Choose a pack size 3 options

Available product options (19)
Single Flute Pilot Panel Bits with Drill-Through Point
from

High Cutting Performance for Flush Trimming

Premium-quality micrograin carbide tips are ground on specialized CNC equipment for an extra-fine finish with maximum sharpness and edge retention. Pilot panel bit has a drill-through point that plunges through the material, and is used for window and door cutouts in abrasive insulation materials, plywood, and paneling.

View more

Product Options

Available product options: 19

Model number Shank Inch Diameter (D) Inch Working length (L) Inch Pack quantity
85146 1/4 1/4 3/4 1
85146B50 1/4 1/4 3/4 50
85147 3/8 3/8 7/8 1
85147B50 3/8 3/8 7/8 50
85188 1/2 1/2 1 1/8 1
85244 1/4 1/4 3/4 35
85244B50 1/4 1/4 3/4 50
85245 3/8 3/8 1 1
85245B50 3/8 3/8 1 50
85245M 3/8 3/8 1 1
85245MB50 3/8 3/8 1 50
85245MC 3/8 3/8 1 1
85245SB50 3/8 3/8 1 50
85245SMC 3/8 3/8 1 1
85246 1/2 1/2 1 3/16 1
85246B50 1/2 1/2 1 3/16 50
85246M 1/2 1/2 1 3/16 1
85246MB50 1/2 1/2 1 3/16 50
85407M 1/2 1/2 2 1
