GCL100-80C Professional
12V Max Line Lasers
12V Max Connected Cross-Line Laser with Plumb Points
- All-in-one use – facilitates one-person job setup with horizontal leveling, vertical alignment and plumb point transfer, and more
- Built-in VisiMax™ technology – delivers maximum beam brightness, optimized energy efficiency and long-term tool reliability
- Bosch Leveling Remote App – free app turns laser on and off, selects operating modes, adjusts visibility and provides alerts
- 12V Max Lithium-Ion power – features long runtime for complex or all-day layout jobs
- Bright laser lines – has a visible range of 100 Ft. with an accuracy of ±1/8 In. at 30 Ft. for confidence in the job setup
- Pulse receiver mode – use an optional laser receiver (LR 6 or LR8) for applications with a 165 Ft. working range
- Smart Pendulum System – self levels, indicates out-of-level condition, and locks pendulum for safe transport
- RM 2 Magnetic Rotating Mount – included accessory rotates 360° while staying centered on the plumb point and offers fine adjustment knob
- Ceiling grid clip – provides easy setup in ceiling-grid applications
- Robust over-molded construction – for years of dependable operation
- Manual mode – locks lines for use at any angle
- Bosch measuring and layout tools are covered by a one year limited warranty with an additional year when you register your tool within eight weeks of purchase - for details, visit https://rb-pt.io/PowerToolWarranty or call 1-877-BOSCH99
- Bosch 12V Max batteries and chargers are covered by a one year limited warranty - for details, visit https://rb-pt.io/PowerToolWarranty or call 1-877-BOSCH99
Functions & key features
Technical data
The most important data |
|
|---|---|
| Connected | Yes |
| Height in | 4.8 " |
| IP Rating | IP 54 |
| Laser Beam Color | Red |
| Laser Diode | Class 2, 630 – 650 nm |
| Length in | 5.4 " |
| Leveling Type | Self-Leveling, Up to 4° |
| Material | Plastic with over-mold |
| Mount Threading | 1/4-20 |
| Operating Temperature | 14° F / -10° C ~1 22° F / 50° C |
| Range | Up to 100-ft. |
| Weight | 1.4 lb |
| Width in | 2.2 " |
| Works With | Laser Receivers, LR 6, LR8, Tripods, BT 150, Telescoping Pole System, BP350, Grade Rods, GR 16, GR500, Mounts and Positioning Devices, BM 1, BM3, RM 1, RM 2, LB10, Batteries, BAT414, Chargers, GAL12V-20, GAL12V-40, GAX1218V30 |
| Includes |
(1) GCL100-80C 12V Max Connected Cross-Line Laser with Plumb Points (1) RM 2 Mount (1) 12V Max Lithium-Ion 2.0 Ah Battery (1) 12V Max Lithium-Ion Battery Charger (1) Ceiling Grid Clip (1) Laser Target Plate (1) Heavy-Duty Pouch (1) Hard Carrying Case |
GCL100-80C Professional: Further information
Product Highlights
The Bosch GCL100-80C 12V Max Connected Cross-Line Laser with Plumb Points delivers all-in-one versatility, with highly visible lines and points. They provide horizontal level, vertical alignment and plumb point transfer applications. The tool features Bosch-exclusive VisiMax™ technology, which monitors tool temperature and power consumption to deliver the brightest line for the job. The laser features Bosch 12V Max Lithium-ion power for extended laser runtime during complex or all day layout jobs, provides a visible range of 100 Ft. and can work with an optional Bosch laser receiver to extend that range to 165 Ft. The Smart Pendulum System self-levels up to ±4°, indicates out-of-level condition and locks for safe tool transport. The manual mode locks lines for use at any angle. The laser comes with the RM 2 Magnetic Rotating Mount that rotates 360°, has a micro-fine adjustment knob and includes a ceiling grid clip.
